Productdescription
The Siemens SQM10 is a reversible electromotoric actuator designed for the precise control of air dampers and valves in oil burners. This specific configuration offers a nominal torque of 10 Nm and a running time of 42 seconds for a 130 degree rotation. It features a locking-proof synchronous motor and a maintenance-free gear train with self-lubricating bearings, housed within an impact-proof, heat-resistant plastic cover. The actuator includes a disengagement lever for manual adjustment and allows for switching point customization via adjustable cams.
Productspecifications
Productname | Servomotor |
Servo direction | Countreclockwise |
Brand | Weishaupt GmbH |
Category | Burner and accessories |
Originally from | Germany |
Model | SQM 10 |
Shaft diameter | 10mm |
Running time and rotation | 42s/130 |
Start torque | 15Nm |
Protection class | IP54 |
Power supply | AC 220...240 V, 50 Hz -15%/+10% |
Housing Material | Die-cast aluminum (gear train) / Plastic (cover) |
