Surface-Mounted Thermostat ATHs-SE-20 50-300 °C 603031/20

ART ID: 6

KM-nummer: KM0006

Artikelnummer: 603031/20 Categorie:

Beschrijving

Productdescription

The JUMO ATHs-SE-20 is a marine-certified surface-mounting thermostat designed for monitoring seagoing vessel equipment, operating as a safety temperature monitor (STW) or safety temperature limiter (STB) with a maximum probe temperature of 300°C. This robust device features a microswitch with changeover contact rated for AC 230V at 10A, IP54 protection rating with aluminum die-cast housing, and is available with stainless steel or copper temperature probes (Ø6mm or Ø8mm) connected via standard 1000mm capillary length. Approved by DNV and BV with CE, UKCA, and EAC conformity marks, the thermostat offers switching point accuracy of +0/-5% in the upper third of scale and includes self-monitoring safety features that permanently open the electrical circuit if the measuring system fails. With G1/2″ screw-in thermowell process connections and reliable operation. Furthermore the ATHs-SE-20 is ideal for heating/cooling systems, climate monitoring, and machine rooms in demanding marine environments.

Productspecifications

Model type

ATHs-SE-20 (603031/20)

Material

Copper, Stainless Steel

Productname

Thermostat ATHs-20-SE 300°C

Brand

Jumo GmbH & Co. KG

Category

Instrumentation/Thermometers

Switching capacity

10 A, 230 V

Max temperature

300 °C

Originally from

Germany

Switching elements

Single wire switching contact

Protection class

IP54

Certificates

DNV, GL, Bureau Veritas, DIN, DGRL, EAC

Features

Single thermostat

Diameter

10 mm

Documents

Technical data
