Productdescription
The model 212.20 is a mechanical Bourdon tube pressure gauge built with a durable stainless steel case. Its wetted parts are constructed from either copper alloy or stainless steel, selected based on the required scale range. WIKA produces and certifies this gauge in compliance with both EN 837-1 and ASME B40.100 standards, incorporating a blow-out device as a key safety feature to vent overpressure during a failure. This versatile instrument is suitable for applications in machine building, plant construction, building services, and refrigeration industries. Available in 100 mm and 160 mm case sizes, it provides IP54 ingress protection. The gauge’s modular design offers a wide variety of combinations for process connections, sizes, and scale ranges, ensuring its adaptability for universal industrial use. For panel mounting, the gauge can be supplied with a mounting flange or a triangular profile ring and bracket.
Productspecifications
Model type | 212.20.100 |
Functionality | This instrument is engineered for industrial applications demanding high accuracy and excellent readability, even from a distance. It is suitable for measuring gaseous or liquid media, provided they are not highly viscous, do not crystallize, and are compatible with the material of the measuring element |
Material alloy | Copper |
Material case | Stainless steel (RVS) |
Productname | Manometer |
Brand | WIKA Alexander Wiegand SE & Co. KG |
Category | Instrumentation/Manometers |
Display range | 0 / +16 bar |
Originally from | Netherlands |
Connection | G ½ B, SW 22 |
Protection class | IP54 |
